Let me introduce the possible batteries for mobility.

BTS-2430B

LiFePO4 Battery
24V 300Ah

Battery Characteristics

  • 7,680Wh
    Capacity

  • Continous
    Discharge 200A
    PEAK 400A

  • Auto Relay
    Reset Safety device

  • -25˚C ~ 60˚C
    Wide Operating
    Temp range

  • A/S
    2years

Application

Specification

Pack Config. 8S 1P
Capacity 300A, 7680Wh
Nominal Voltage 25.6V (3.2V/Cell)
Discharge Cut-off Voltage 22.4V (2.5V/Cell)
Charging Voltage 29.2V (3.65V/Cell)
Standard Charge 0.3C Constant current to 29.2V, then constant voltage to 0.05C
Standard Discharge 0.6C Constant current up to 20V
Nominal Charge Current 100A
Maximum Continuous Charge/Discharge Current 200A (BMS)
Operation Temperature Charge : 0~55℃
Discharge : -20~60℃
Storage Temperature Less than 12 months : -20~25℃
Less than 3 months : -20~45℃
Less than 1 month : -20~60℃
Size 400(435) X 305 X 275mm
Weight 52kg

High Performance BMS

  • Over Charge Protection

  • Over Discharge Protection

  • Over Current Protection

  • Over Temperature Protection

  • Cell Balancing Function

  • Short Circuit Protection

Battery Characteristics Graph

  • C-Rate Curve

    C-Rate

  • Cycle life

    Cycle life

  • Discharge Temperature Characteristics

    Discharge Temperature

  • Charge and Discharge at 25˚C, 0.2C

    Charge and Discharge

※ C-Rate means that a fully charged 1Ah battery is discharged to 1A for 1 hour.
